Centurion, T10SMART Tip-Up Garage Door Opener

Code: T10SMART

Category: Gate Operator

Description:

Technical Specifications:
T10
Input voltage 230V AC +/-10% @ 50/60Hz
Motor voltage 24V DC
Motor power supply – rated 80W DC
Motor supply Battery supply 2 x 3.4Ah 12V DC
Maximum door width 6.5 meters
Maximum door area 12 Square meters
Maximum push/pull force 40kgf
Maximum lifting capacity 1000N
Operations in standby mode Up to 90 dependent on door size, weight, height and duration of power failure / condition of batteries
Maximum operator travel speed3 9m/min
Door travel adjustment Physical end-stops (Automatic limit set)
Safety obstruction force system Built-in menu
Light LED 2W
Autoclose2 Menu Selectable
Infrared safety beams Menu Selectable (Optional but recommended)
Onboard receiver type Code-hopping single channel
Receiver code storage capacity 20x 4-Button Transmitters
Receiver frequency 433.92Mhz
Degree of protection IPX0 (For interior use only)
