Can be connected to parking management components such as vehicle proximity sensors, remote security access systems, RFID readers (RFID Cards, RFID Stickers), Plate Recognition systems, Alarms, Boom Barriers and Parking Spikes Barriers and more!
Effective Infrastructure
Leverage on the usage of existing network infrastructure, hence
saving your cost.
Adaptive Network Bandwidth
High bandwidth with high speed polling transmits data easily,
enabling real-time transaction to the users.
MICROCONTROLLER (MCU): FREESCALE CF 32 bits @ 60mHz
MEMORY: 1024 kb EEPROM & 16 Mb FLASH
BATTERY CHARGER (12 VDC ): 12VDC / 7AH (Onboard battery backup charger)
OPERATING TEMPERATURE: 0°C to 55°C
HUMIDITY RANGE: 0-85% non-condensing
CARD HOLDER: 75,0000(upgradable to 150,000)
EVENT: 40,0000(upgradable to 80,000)
READER TECHNOLOGY: Standard Wiegand (26 bit to 64 bit)
READER SUPPORTED: 1 door (2 readers) / 2 doors (4 readers) -12vDC @200mA per reader port
INPUT POINTS ON-BOARD: 4 (Fire / Tamper / Door Contact /Exit Push Button)
SECURITY ENCRYPTION: AES-128
HOLIDAYS | TIME ZONES: 50 | 3
TIME SETS | TIME SETS INTERVAL: 50 | 3
SOFTWARE USER LEVEL: 3 (web 100)
COMMUNICATION TYPE: RJ45 Ethernet | 10/100Base-T (Max 100m/328ft)
NETWORK PROTOCOLS: TCP/IP, ARP, DHCP
BOARD DIMENSION | WEIGHT: 137 (L) x 117 (W) x 15.5 (H) mm | 25g (w/o casing)
CERTIFICATIONS: CE RoHS
SECURITY ENCRYPTION: AES-128
