Falco Door Access Out Board Module – Integration Board
8 relays per module, up to 64 per controller
8 relay outputs per module
Up to 8 modules per controller (64 total relays)
SPDT configuration (NO/NC/COM)
5A contact rating per relay
Controls locks, alarms, and auxiliary devices
Per-relay LED status indicators
Screw terminal connections
DIN rail or wall mountable
| Outputs | 8 relay outputs per module |
| Max Modules | 8 per controller (64 total relays) |
| Relay Type | SPDT (NO/NC/COM) |
| Contact Rating | 5A @ 250V AC, 5A @ 30V DC |
| Terminal Type | Screw terminals |
| Communication | Wired to controller |
| Power | 12V DC external or controller |
| LED Indicators | Per-relay status LED |
| Dimensions | 120 x 70 x 30mm |
| Mounting | DIN rail or wall mount |
