Features:
Regulated and Filtered
Surge Protected
LED Indicator for each channel
110V AC Input
Total Output Current : 10A
Total Outputs :18
Fuse Type : PTC (Resetable)
General protection: each output has independent PTC fuse and LED indicator, when problem occurs, only affect the independent output, other outputs still working.
Circuit short protection: when short condition occurs, independent PTC fuse will open the circuit,when condition removed, PTC fuse will automatically back to close.
High voltage protection: when high voltage occurs, the surge protection will be hit through to protect the connected device.
Over Current protection: when over current occurs, the power supply will automatically switch to self-protection status, when condition removed, then switch back to normal.
Application : CCTV Camera, PTZ, IR illuminator, Video Processor, Access Control , etc.
Code: PS-DC10A04UPC
Category: Accessories
Subcategory: PSU
Brand: Centro
Description:
Features:
-12 Volt DC 120V/240V switching power supply. Connect and power 9 devices
-UL / cUL recognized to meet safety requirements
-Fan-less transformer to reduce noise. Each output comes with its own fuse and LED indicator
-10 Amps continuous current. 120 Watts total power output. 12V 2A per port, 10A total shared.
-Fuse Type : PTC (Resetable) Fuse Rating : 2.3Av
-Punch-out holes for allowing cable access are available on the following sides: Heavy duty solid construction for installation in any environment.
